Low temperature manual ball valve used in ethylene, liquefied natural gas, LNG, chemical equipment, liquefied natural gas carrier, air separation equipment, petroleum, chemical tail gas separation equipment, liquid oxygen, liquid nitrogen, liquid argon, carbon dioxide cryogenic storage tank and tank lorry, psa oxygen generation, etc.
Design features
?Design of long neck bonnet
?Fire safety design
?Anti-static design
?The minimum thermal expansion coefficient
?Efficient heat conduction
?Actuator: manual, worm wheel, pneumatic, electric actuator
Applicable standards
ISO 9001 quality requirements
BS6364 valve general design requirements
ANSI B16.5 valve flange connection standard
ANSI B16.25 valve butt welding standard
ANSI B16.34 pressure temperature rating standard
BSEN 10204 3.1/3.2 material application
Product range
Size range: 2 "~ 12" (DN50 ~ DN300)
Pressure range: 150LB ~ 600LB (PN10 ~ PN100)
Temperature range: - 196 ℃ to 60 ℃, 320 ℉ ~ 140 ℉
Main material: LCB, LC3, CF8, CF8M |
